AWSTemplateFormatVersion: "2010-09-09"

Parameters:
  PublicIP:
    Type: String
    Description: "Public IP address of the on premise"

  OnPremiseSubnet:
    Type: String
    Description: "Subnet in the on premise network"

Resources:
  VPC:
    Type: AWS::EC2::VPC
    Properties:
      CidrBlock: 10.1.0.0/18
      EnableDnsSupport: true
      Tags:
        - Key: Name
          Value: VPN AWS & on prem

  PrivateSubnet01:
    Type: AWS::EC2::Subnet
    Properties:
      AvailabilityZone: !Select
        - 0
        - Fn::GetAZs: !Ref "AWS::Region"
      VpcId: !Ref VPC
      CidrBlock: 10.1.10.0/24
      Tags:
        - Key: Name
          Value: "[PRIVATE-01] VPN AWS & on prem"

  PrivateSubnet02:
    Type: AWS::EC2::Subnet
    Properties:
      AvailabilityZone: !Select
        - 1
        - Fn::GetAZs: !Ref "AWS::Region"
      VpcId: !Ref VPC
      CidrBlock: 10.1.20.0/24
      Tags:
        - Key: Name
          Value: "[PRIVATE-02] VPN AWS & on prem"

  RouteTable:
    Type: AWS::EC2::RouteTable
    Properties:
      VpcId: !Ref VPC
      Tags:
        - Key: Name
          Value: VPN AWS & on prem

  RouteTableAssociatePrivateSubnet01:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref PrivateSubnet01
      RouteTableId: !Ref RouteTable

  RouteTableAssociatePrivateSubnet02:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref PrivateSubnet02
      RouteTableId: !Ref RouteTable

  CustomerGateway:
    Type: AWS::EC2::CustomerGateway
    Properties:
      BgpAsn: 65000
      IpAddress: !Ref PublicIP
      Type: ipsec.1
      Tags:
        - Key: Name
          Value: VPN AWS & on prem

  VirtualPrivateGateway:
    Type: AWS::EC2::VPNGateway
    Properties:
      AmazonSideAsn: 64512
      Tags:
        - Key: Name
          Value: VPN AWS & on prem
      Type: ipsec.1

  AttachVirtualPrivateGatewayToVPC:
    Type: AWS::EC2::VPCGatewayAttachment
    Properties:
      VpcId: !Ref VPC
      VpnGatewayId: !Ref VirtualPrivateGateway

  VPNConnection:
    Type: AWS::EC2::VPNConnection
    Properties:
      CustomerGatewayId: !Ref CustomerGateway
      StaticRoutesOnly: true
      VpnGatewayId: !Ref VirtualPrivateGateway
      Type: ipsec.1
      Tags:
        - Key: Name
          Value: VPN AWS & on prem

  AttachRouteToVPNConnection:
    Type: AWS::EC2::VPNConnectionRoute
    Properties:
      DestinationCidrBlock: !Ref OnPremiseSubnet
      VpnConnectionId: !Ref VPNConnection

  PropagateOnPremiseSubnetToRouteTable:
    Type: AWS::EC2::VPNGatewayRoutePropagation
    DependsOn:
      - AttachVirtualPrivateGatewayToVPC
    Properties:
      RouteTableIds:
        - !Ref RouteTable
      VpnGatewayId: !Ref VirtualPrivateGateway

/ip firewall filter
add action=accept chain=input comment="AWS VPN Frankfurt IPSec" dst-port=500,4500 \
    protocol=udp

/ip ipsec profile
add dh-group=modp1024 dpd-interval=10s dpd-maximum-failures=3 enc-algorithm=\
    aes-128 lifetime=8h name=aws-vpn-frankfurt-ipsec-profile

/ip ipsec peer
add address=TUNNEL_OUTSIDE_IP/32 comment="AWS VPN Frankfurt IPSec" local-address=YOUR_PUBLIC_IP name=aws-vpn-frankfurt-ipsec-peer \
    profile=aws-vpn-frankfurt-ipsec-profile

/ip ipsec proposal
add comment="AWS VPN Frankfurt IPSec" enc-algorithms=aes-128-cbc lifetime=1h name=aws-vpn-frankfurt-ipsec-proposal


/ip ipsec identity
add peer=aws-vpn-frankfurt-ipsec-peer comment="AWS VPN Frankfurt IPSec" secret=SECRET_HERE

/ip ipsec policy
add dst-address=10.1.10.0/24 comment="AWS VPN Frankfurt IPSec" peer=aws-vpn-frankfurt-ipsec-peer proposal=\
    aws-vpn-frankfurt-ipsec-proposal sa-dst-address=TUNNEL_OUTSIDE_IP sa-src-address=\
    YOUR_PUBLIC_IP src-address=192.168.88.0/24 tunnel=yes
